Summary: Custom wet bench systems enhance precision, safety, and efficiency in semiconductor processing by providing tailored solutions for research and high-volume manufacturing.

Table of Contents

Introduction  1

Key Aspects of Wet Bench Customization  1

Wet Bench Configuration Options 2

Customization for Different Applications 4

Processing Acids vs. Solvents: Key Considerations 5

Wet Processing Equipment Components to Support Different Processes 7

Benefits of Using Modutek’s Custom Wet Bench Systems 10

Choosing the Right Wet Bench System   10

Conclusion & Next Steps 12

Introduction

In semiconductor research and production, precision is everything. Successful fabrication depends on accurately controlled chemical reactions, cleaning processes, and etching techniques. Wet bench systems are critical in delivering this precision, ensuring every step—whether in R&D or high-volume production—meets exacting standards.

The demand for customization arises from diverse needs across the industry. Research labs demand adaptable systems for experimentation, while manufacturers require reliable, consistent performance. From handling aggressive chemicals to meeting strict temperature and timing controls, custom wet benches optimize efficiency and safeguard process integrity.

With semiconductor technology advancing rapidly, wet bench systems must keep pace, offering scalability, advanced process control, and long-term reliability. This article explores how tailored wet bench solutions deliver the performance needed for semiconductor industry needs.

Key Aspects of Wet Bench Customization

Successful wet bench system implementation relies on four foundational elements that determine operational effectiveness and long-term value. Each aspect requires careful consideration during system design to ensure optimal performance and reliability.

Safety and Operator Protection

Modern wet bench systems must comply with industry safety standards. Built-in systems protect both operators and process integrity. Some of the most critical features include emergency shutdown mechanisms, advanced ventilation systems, spill containment, real-time monitoring of chemical levels, and motion-control safeguards with interlock systems.

Process Control for Reliability and Consistency

Semiconductor fabrication requires automated tracking and meticulous process control. Key features include real-time chemical monitoring, automated sequence regulation, process timing controls, and comprehensive data logging. These elements ensure repeatable processing results and higher-quality outcomes.

Material Selection for Durability and Chemical Resistance

The materials used in wet processing systems must withstand harsh chemical conditions. Teflon and polypropylene tanks resist corrosion, high-purity materials reduce contamination risks, and thermally stable components help maintain uniform processing conditions.

Facility Integration for Efficiency and Scalability

A well-designed wet bench integrates seamlessly with facility infrastructure and production workflows. Cleanroom compatibility, space optimization, modular scalability for future expansion, utility connection planning, and effective waste management all contribute to a more efficient and flexible system.

Addressing these factors ensures efficient, long-lasting, and safe wet processing operations.

Wet Bench Configuration Options

Wet bench systems come in three distinct configurations: manual, semi-automated, and fully automated. Each is designed to meet specific operational requirements and processing needs. Understanding these options helps organizations select the most appropriate system for their applications.

Manual Wet Benches – Maximum Control for R&D

Manual wet bench stations provide direct operator control and are ideal for research and prototyping. These systems allow scientists to manipulate parameters in real time, making them suitable for developing new semiconductor processes.

Example: A university research facility developing novel nanoscale etching techniques uses a manual wet bench to test and refine the process.

These systems excel in research environments where:

• R&D needs direct parameter flexibility
• Process development requires frequent adjustments
• Experimental protocols change regularly
• Hands-on control enhances process understanding

Semi-Automated Wet Benches – Balance of Flexibility and Efficiency

Semi-automated wet benches combine operator control with programmable sequences. These systems enable precise adjustments while allowing for repeatable, standardized processes, making them suitable for low-to-moderate production environments.

Example: A small semiconductor fabrication plant utilizes a semi-automated wet bench to transition from pilot testing to limited manufacturing.

These hybrid systems are best in environments that require:

• Programmable sequences for routine operations
• Operator intervention capabilities when needed
• Process monitoring with manual override options
• Flexible programming features

Fully Automated Wet Benches – High-Volume Production Optimization

Fully automated wet benches are designed for high-throughput semiconductor production. These systems minimize human intervention, ensuring consistent processing and reducing handling errors.

Example: A semiconductor manufacturer integrates a fully automated wet bench system, reducing production cycle times by 30 percent while maintaining strict process uniformity.

These sophisticated systems deliver:

• Complete process automation and control
• High-volume production capabilities
• Consistent results across multiple batches
• Minimal operator intervention requirements

Factors to Consider When Selecting a Configuration

The right wet bench setup depends on process complexity, production volume, chemical compatibility, staff expertise, and long-term scalability. A thoughtful selection ensures greater efficiency and higher yield outcomes.

Customization for Different Applications

Semiconductor processing demands vary significantly between research and manufacturing environments. Understanding these distinct needs drives effective system customization for optimal performance in each setting.

Research and Development Applications

Research facilities require systems optimized for experimental flexibility and precise control. Key customization features include:

• Rapid parameter adjustment capabilities
• Multiple chemical process compatibility
• Customized data collection systems
• Quick recipe changes
• Process customization capabilities

Manufacturing Operations

Production environments focus on consistency, efficiency, and yield. Critical system elements include:

• High-throughput capabilities
• Process repeatability features
• Quality control integration
• Production monitoring tools

These features deliver manufacturing success through:

• Consistent yield results
• Efficient throughput rates
• Quality standard compliance
• Reduced operational costs
• Minimized downtime

Scalability and Adaptation

Modern wet bench systems incorporate features supporting growth and evolution:

• Modular design for custom layout
• Process flow adaptability
• Component upgrade options

This forward-thinking approach ensures systems can adapt to:

• Increasing production demands
• New process requirements
• Changing quality standards
• Different market opportunities

Each customization aspect directly addresses specific operational requirements while maintaining system flexibility. This targeted approach ensures optimal performance in both research and manufacturing applications, delivering immediate value while supporting future growth.

Processing Acids vs. Solvents: Key Considerations

Chemical processing in semiconductor applications requires specialized system configurations based on the specific materials being handled. Understanding the distinct acid and solvent processing requirements ensures safe, efficient operations.

Comparison of Acid and Solvent-Based Processing

Acid Processing Requirements

Systems handling acid-based processes need specific design elements for etching, cleaning, and oxide removal:

Material Requirements:

• Teflon tanks for base processing and other aggressive acids
• Corrosion-resistant components
• Chemical-specific containment solutions

Process Controls:

• Temperature regulation systems
• Concentration monitoring tools
• Quick dump rinser integration
• Acid Neutralization capabilities

Solvent Processing Specifications

Solvent-based applications, focusing on photoresist stripping and organic contamination removal, demand different configurations:

System Design:

• Stainless steel construction for solvent compatibility
• Solvent and Sub-ambient bath capabilities
• Specialized ventilation systems
• Temperature control features

Safety Features:

• Fire prevention systems
• VOC monitoring equipment
• Explosion-proof components
• Enhanced ventilation controls

Key Considerations for Each Processing Type

Acid-based processing requires specialized chemical resistance and precise temperature control to ensure uniform etching. In contrast, solvent-based processing demands fire prevention systems and enhanced vapor extraction to manage volatile organic compounds. Modern wet bench systems incorporate these specific requirements while maintaining process efficiency and operator safety.

Wet Processing Equipment Components to Support Different Processes

The success of semiconductor processing relies on specialized components working together to deliver precise, repeatable results. Each component plays a vital role in system performance and process quality.

Primary Processing Components

Chemical Delivery Systems
Modern chemical management delivers precise process control through:

• Automated ratio control for mixing
• Real-time concentration monitoring
• Direct chemical path routing
• Integrated replenishment features

Environmental Control
Advanced air scrubbers protect facility operations with the following:

• Multi-stage chemical filtration
• Energy-efficient operation
• Local monitoring capabilities
• Automated adjustment systems

Process Specific Equipment Components

Heated Quartz Tanks: Advanced heating systems designed for high-temperature chemical processing up to 165°C while maintaining chemical purity and process visibility.

• Temperature uniformity
• Process observation capability
• Extended service life
• Contamination prevention

Teflon Tanks: Specialized tanks engineered for aggressive acid-based etching processes, offering maximum chemical resistance and process flexibility.

• Aggressive chemical compatibility
• Extended operational life
• Maintain chemical purity
• Easy maintenance access
• Process adaptability

Quick Dump Rinsers: High-speed rinsing systems that remove chemicals from wafers quickly and efficiently while conserving water resources.

• Rapid chemical removal
• Water conservation features
• Programmable cycles
• Process optimization

Solvent Baths and Sub-Ambient Baths: Temperature-controlled processing stations designed for precise solvent-based operations and low-temperature applications.

• Temperature stability
• Solvent compatibility
• Safety features integration
• Process consistency

Wet Processing Temperature Control Circulation Systems: Thermal control solutions that maintain precise process temperatures across different applications.

• Process-specific control
• Energy optimization
• Process monitoring
• Temperature uniformity

Transfer Mechanisms: Automated handling systems that ensure precise movement of materials between process stations.

• Position accuracy
• Process timing control
• Multiple process support
• Safety interlocking
• Operational flexibility

Integration Capabilities

Integration capabilities tie these components into cohesive systems supporting multiple process types. The integrated approach ensures:

• Seamless operation across different processes
• Central control of all system components
• Comprehensive data logging for process tracking
• Local monitoring capabilities
• Flexible adaptation to changing requirements

These specialized components create complete processing solutions that handle diverse requirements, from research and development to full-scale production. Their adaptability ensures consistent, reliable results while maintaining safety and efficiency, whether processing small experimental batches or managing high-volume manufacturing.

Benefits of Using Modutek’s Custom Wet Bench Systems

With over four decades of semiconductor processing expertise, Modutek delivers high-precision wet bench systems that address complex industry challenges. Modutek’s approach combines advanced technology with deep application knowledge to serve diverse processing needs.

Advanced Precision and Performance

Modutek’s custom wet benches incorporate automated parameter tracking, high-purity materials, and data-driven monitoring for reliable, repeatable results. Process consistency improves overall production yield and reduces operational variability.

Scalability and Future-Proof Design

Modutek’s modular wet bench systems allow for incremental capacity expansion. Integration with advanced facility automation and remote monitoring capabilities ensures systems remain adaptable to evolving semiconductor processing needs.

Safety and Regulatory Compliance

Built-in safety features include chemical containment systems, automated ventilation, and real-time exhaust tracking. Modutek’s solutions fully align with industry standards that include S8, S22, IEC.EN, Structural PE, Seismic PE, and Title 22. Systems can be designed to comply with additional standards, including the following:

• UL/ETL -Standards for Industrial Control Panels
• NFPA 70- NEC -Standard for National Fire Protection and the National Electrical Code
• NFPA 79 -Standard for Safety of Industrial Machinery
• CSA (Canadian Standards)
• CE (European Standards)
• Ashare

These benefits enhance efficiency, longevity, and cost-effective operation in research and production environments.

Choosing the Right Wet Bench System

Selecting an appropriate wet bench system requires careful consideration of multiple factors. Modutek’s experience helps guide customers during this critical decision-making process, ensuring optimal system selection for specific processing needs. Several key factors must be considered to ensure the system aligns with production and research needs.

Process Requirements

A wet bench system must be designed to handle the specific chemical processes involved in semiconductor fabrication. Critical considerations include:

• Chemical Compatibility – The system materials must be resistant to the specific acids or solvents used in processing. Teflon tanks, stainless steel construction, and chemical-resistant coatings ensure long-term durability.
• Temperature Control – Some processes require high-temperature etching, while others rely on sub-ambient solvent baths. The chosen system must accommodate precise thermal regulation.
• Process Timing and Automation – Automated timing and sequence management reduce processing variability, ensuring repeatable results across multiple batches.
• Batch Handling Capacity – The system’s tank size and throughput capacity should align with current production needs while allowing for future scaling.

Safety Standards and Compliance

Ensuring worker and facility safety is essential in semiconductor manufacturing environments. A properly designed wet bench system should incorporate:

• Chemical Containment – Built-in storage and disposal systems minimize direct exposure to hazardous materials.
• Ventilation and Exhaust – Proper fume extraction mitigates airborne contamination and meets environmental regulations.
• Emergency Response Mechanisms – Integrated shutoff controls, leak detection, and chemical neutralization systems add critical safety layers.
• Regulatory Compliance – Systems should adhere to industry standards such as SEMI S2 and ISO regulations for cleanroom compatibility.

Integration with Facility Infrastructure

A new wet bench system must seamlessly integrate with existing facility layouts, automation systems, and production workflows. Key integration aspects include:

• Space Utilization – The layout should optimize floor space and accommodate maintenance accessibility.
• Cleanroom Compatibility – The system should support contamination control standards and meet environmental cleanliness levels.
• Data Logging and Monitoring – Integration with process control systems enables real-time tracking of chemical usage, temperature, and operational parameters.
• Scalability for Future Needs – Modular wet bench designs allow for expansion or reconfiguration as production demands grow.

Expert Guidance for System Selection

Modutek provides engineering expertise to help semiconductor manufacturers select and customize wet bench solutions. Their team evaluates:

• Current and anticipated processing requirements
• Chemical handling and safety needs
• Automation levels for operational efficiency
• Long-term reliability and maintenance considerations

A properly selected wet bench system ensures optimized process control, enhanced safety, and long-term cost savings while supporting future technology advancements.

Conclusion & Next Steps

Custom wet bench systems are a critical investment in semiconductor fabrication, offering the precision and repeatability needed for both research and large-scale manufacturing. Proper customization ensures systems align with specific chemical processes, automation levels, and facility requirements.

Well-design wet bench systems provide several key advantages, including:

• Precise Process Control – Automated monitoring and real-time adjustments improve consistency.
• Enhanced Operational Efficiency – Optimized workflows and safety measures reduce downtime and processing errors.
• Long-Term Cost Savings – Durable material selection and process automation reduce maintenance and operational costs.

For research labs, custom wet bench solutions enable greater flexibility when experimenting with new materials and process flows. Automated wet benches ensure repeatable, high-yield fabrication in high-volume semiconductor production while improving workplace safety and compliance.

Get a Custom Wet Bench Tailored to Your Needs

Choosing the right wet processing solution requires expert guidance to ensure maximum efficiency and safety. Modutek provides industry-leading wet benches engineered to meet the unique requirements of semiconductor manufacturing.

As semiconductor technology advances, the importance of precise, reliable wet processing equipment grows. As a leading semiconductor equipment manufacturer, Modutek is dedicated to engineering excellence and ensures that each customer receives a system that meets current challenges while providing a foundation for future growth.

Are you looking for a custom wet bench solution tailored to your exact needs? Contact Modutek to schedule a free consultation to explore configurations that improve efficiency, safety, and cost-effectiveness.
