Not every advancement in semiconductor fabrication produces results that are usable in industry. To be of value, advancements need to be consistently repeatable when used on an industrial scale. Modutek’s IPA vapor dryer falls into this category, helping semiconductor fabricators improve both yields and processing times.
Modutek’s IPA vapor dryers are custom-engineered with in-house experts working in partnership with a client’s technical staff. From a thorough understanding of a client’s manufacturing process, Modutek works to make sure their equipment is designed and tested to meet the requirements.
The Marangoni IPA Vapor Dryer Design
Silicon wafers require cleaning, rinsing and drying at certain stages of the fabrication process. The results need to be as close to perfection as possible, with no watermarks, and minimal particle contamination. In the past, these results were obtained through rapid spinning and heat drying. These simple methods no longer work with the latest high-density wafers, however. Not only is water hard to remove from complex shapes, drying without leaving watermarks is impossible.
Contamination from incorrect cleaning and drying can cause serious product malfunction and high failure rates. This is where drying by isopropyl alcohol comes into play. IPA drying by the vapor method, delivers wafers that are completely free of watermarks and with minimal contamination. Modutek’s IPA vapor drying system is both cost-effective, and ready for seamless integration into the standard wet bench process or free-standing design.
How the IPA Vapor Dryer Design Works
Modutek’s IPA vapor dryer design is unique in a number of ways. This design delivers high-quality results through serving IPA vapor at the upper reaches of the drying tank. This makes sure that vapor distribution is even. Since the surface tension of isopropyl alcohol is lower than that of water, such vapor serving introduces a gradient of surface tension where isopropyl alcohol meets with a layer of water on the wafer surface. With this type of drying effect, water quickly leaves the wafer surface, and leaves it completely dry and clean. Since the water does not actually evaporate, it leaves the watermarks behind. The drying process takes no longer than 15 minutes.
The Advantages of Modutek’s IPA Vapor Dryer
Modutek’s in house experts in IPA vapor dryer design work together with a clients’ technical team to design and create IPA dryers that specifically meet their application requirements. Clients are able to come to Modutek’s facility for testing to make sure that their equipment works as expected.
With extensive experience in the wafer processing industry, Modutek is fully able to provide top-notch equipment and customer support at every stage of the design process, during delivery and after the sale. With expertise in semiconductor processing equipment, Modutek is able to address every specific client need for this industry. Contact Modutek for free consultation on the equipment needed for your specific wafer manufacturing process.
